# Specifications

## Hardware Specifications

* **Processor:** Intel® Celeron N3450 (Apollo Lake), Quad-Core, 1.1GHz (up to 2.2GHz), 2MB L2 Cache
* **Memory:** 8GB
* **Onboard Storage:** 32GB eMMC 5.1

## Ethernet Interface

* **Ports:** 2x Gigabit Ethernet (WAN/LAN)
* **Physical Layer:** 10/100/1000 Base-T (IEEE 802.3)
* **Data Rate:** 10/100/1000 Mbps (Auto-Sensing)
* **Interface:** Auto MDI/MDIX
* **Mode:** Full/Half Duplex (Auto-Sensing)

## Power Supply and Consumption

* **Input:** 12V 3A DC
* **Consumption:** 2.5-4W

## Physical Characteristics

* **Indoor Use Only**
* **Material:** Durable ABS Plastic (White & Black)
* **Dimensions:** 6.1 x 4.6 x 2.2 inches (156 x 117 x 57 mm)
* **Mounting:** Desktop or Wall Mount
* **Weight:** 1.11 lbs

## Environmental

* **Storage Temperature:** -4°F to 140°F (-20°C to 60°C)
* **Operating Temperature:** 32°F to 131°F (0°C to 55°C)

<figure><img src="/files/pyOUkZFj65nOONZUEC6q" alt=""><figcaption></figcaption></figure>

{% file src="/files/hrHNHkalY3oX35lvJFNG" %}

{% file src="/files/5UuUqE9TcKGt2C143aSn" %}
